Many 3D wave-based simulations - such as room acoustics or ground penetrating radar - are complicated to model and even more complex to abstract about. How- ever, such simulations are integral to predicting the properties and behaviour of the physical world around us. Many current high-level parallel methodologies focus on stencil applications, but neglect to manage absorbing boundary conditions which are critical to obtaining coming, this project aims to take advantage of what is available already and create a modularised approach to simulation development for HPC. As the HPC landscape expands, developers need to run their codes on newer, more performant platforms, such as GPUs or Xeon Phis. However, there is a lack of tools that provide performance portability. Instead, programmers are required to rewrite and retune their codes as well as maintain multiple code bases. This can be expensive, time-consuming and prone to error. Computational scientists should be able to focus on their own research and not require HPC expertise. This project will address this issue with a modularised approach to developing performant, portable and productive 3D wave models using existing frameworks.


3D wave-based simulations are an important tool in physics for modeling the evolution of waves through space and time of various mediums. The finite difference time domain method (FDTD) is a widely used numerical approach for modelling of the 3D wave equation. Space is discritised into a three-dimensional grid of points, with data values resident at each point representing the field at that point. The state of the system evolves through time-stepping: the value at each point is repeatedly updated using finite differences of values in the neighbourhood of that point. The so-called stencil of points involved in each update is determined by the choice of discretisation scheme for the partial differential operators in the wave equation. This numerical approach is computationally expensive, but amenable to parallelisation. In recent years, there has been progress in the development of techniques to exploit modern parallel hardware, however much of it is low-level or tied to specific platforms. Ideally, any software should be able to run in a portable manner across different architectures while retaining performance and being straightforward to program.


There are currently a wide range of DSLs, code generators, skeleton libraries and other high-level approaches that focus on stencil applications (ie. Halide, Pochoir, Exastencils and so on). However, these solutions are limited in the types of stencils they focus on and do not offer performance portability. Additionally, because they all focus on stencil applications, there inevitably ends up with similar functionality for common requirements. Ideally, different DSLs could use a common compiler, so that the DSL writers could focus on the abstraction layer at the top. This is where Lift comes in. Lift currently is not “productive” as it is designed to be used as an intermediate language targeted by DSLs to handle low-level implementation and optimisation. The language is built using a com- position of primitives for a wide range of algorithms (including stencils). Then a search space of “rewrite rules” (ie. rules that describe valid transformations of specific primitive compositions) to optimise codes for a particular platform. OpenCL kernels are produced for all the different “rewrites” until an optimal program is found. However, Lift is easily extensible to other low-level parallel programming frameworks besides OpenCL (given its modular design), but so far OpenCL has been the main backend.


Preliminary results have shown that Lift is capable of expressing stencils of varying types and sizes. In particular, simplified room acoustics simulations have been thoroughly investigated in the framework and a number of other 2D and 3D benchmarks have also been implemented. However, the performance of 3D stencils lags behind hand-optimised versions, so current work also involves developing and formalising stencil optimisations for 3D codes, in particular 2.5D tiling. Additionally, ground penetrating radar algorithms are also being implemented. These operate in a similar fashion to room acoustics (using the 3D wave equation and absorbing boundary conditions), but model both the electric and magnetic fields interacting with each other. How to best abstract out absorbing boundary conditions needs to be investigated in more detail and primitives to accommodate these conditions need to be designed and added. Finally, a stencil-based DSL needs to be extended to compile into the Lift language.
